Heated Antechamber Tray

The VAC Heated Tray Vacuum Oven (HTVO) is designed to provide a controlled high temperature vacuum environment for drying, curing, outgassing or other processing of parts and products.

  • Input Power: 100-120 Volts VAC, single phase connection, 10 amps, 50/60
  • Vacuum Pump Inlet: NW25-KF flange connection
  • Vacuum Pump Exhaust Vent: NW25-KF flange
  • Heated Tray Dimensions: 23” L x 11.5”
  • Heated Tray Maximum Temperature:  150°C



200° C Air Cooled Oven

The VTB oven is a heat reflective, insulation blanketed oven for operation to 200° C.

The oven is fabricated using VAC’s stainless steel cylinder, 15” diameter x 24” long, with counterweighted vertically swinging doors. Inconel sheathed heating elements are internally mounted.

The VTB oven has a black anodized muffle with three sliding shelves. The PLC based control system with touchscreen display allows programming of up to 200 timed segments for ramp, soak, evacuation, and inert gas refill from the glovebox. The oven comes standard with a 6.9 cfm vacuum pump. Options include Pirani gauge, oven purge, door interlocks and RS-232 data logging.



200c oven no pump

High Temperature Water Cooled Oven

The oven is fabricated using VAC’s stainless steel cylinder, 15” diameter x 24” long, with counterweighted vertically swinging doors.  Inconel sheathed heating elements are internally mounted.

The VTW oven has a single stainless steel internal shelf. The PLC based control system with touchscreen display allows programming of up to 200 timed segments for ramp, soak, evacuation, and inert gas refill from the glovebox. The oven comes standard with a 6.9 cfm vacuum pump. Options include Pirani gauge, oven purge, door interlocks and RS-232 data logging.



200c oven_
