MD-50 Digital Microscope

A digital Microscope designed for a focused and efficient digital age.

Optical Lens Specifications

  • Zoom range: 0.7X – 4.5X
  • Numerical Aperture: 0.027 – 0.07 • Resolution: about 6μm
  • Working Distance: 94mm

Digital Camera Specifications:

  • Camera Sensor: Sony IMX290(C); Resolution of 1920 x 1080
  • Sensor Size: 1/2.8″; Pixel Size: 2.9 x 2.9 μm
  • 12v DC power supply
  • C Mount adapter, 0.5X
  • HDMI mode: Live image at 1080p / 60 fps
  • Video image capture to SD memory card: 1080p at 30 fps
  • Camera controls via mouse: auto exposure / manual exposure, gain, white balance, color adjustment, sharpness, noise reduction
  • Toolbar: zoom, mirror, comparison, freeze, crossline
front view of the digital microscope that uses a screen to show images.

Comfort and Performance

Stand:

  • Low-profile post stand with fine and coarse focusing

Illumination:

  • LED ring light with intensity control
  • Polarizing filter and rotatable analyzer with graduations

Monitor:

  • 12” diagonal; 11” W / 7” H with 1920 x 1080 resolution • 12v DC power supply
  • Mounts directly to the camera
