GENESIS

NEXGEN

OMNI-LAB

NEXUS-II

Glovebox

• Single (2 port)

• 4, 6 & 8 port via adding additional box modules.

• Single (2 port)

• 4, 6 & 8 port via adding additional box modules.

• Custom designs available

• Single (2 port) OMNI-LAB

• Dual length (4 port-via additional module attachment)

• Custom designs available

• Single sided 2 port, 3 port, 4 port

• Double sided 4 port, 6 port, 8 port

• Custom designs available

Stand

Completely welded. No assembly required.

Can be configured without stand for benchtop mounting.

Completely welded. No assembly required.

Assembled for shipping

• Option to ship disassembled

• Very simple assembly

Completely welded

• No assembly required

• Stand cover panels

Purification

Cartridge based purifiers are installed inside the glovebox.

• 2 three speed blowers, one for O2 and one for H2O

• < 1 ppm O2H2O



NO REGENERATION REQUIRED

Cartridge based purifiers are installed inside the glovebox.

• 2 variable speed blowers one for O2 and one for H2O

• < 1 ppm O2H2O



NO REGENERATION REQUIRED

Mounted on top of box

• Single speed blower

• Single purifier

• Manual isolation valves

• < 1 ppm O2, H2O

Mounted in stand

• Variable speed blower

• Single or double purifier

• Automatic or manual isolation valves

• < 1 ppm O2, H2O

Controls

Box pressure monitoring and control via a panel mounted Photohelic gauge.

Box pressure, blower speeds, smart purifier, auto purge, safe purge controlled via a PLC with touch screen display.

• Touch screen display

• Automated: purifier regeneration, lab pressure, lab purge (manual
exhaust valve), system diagnostics

• Touch Screen Graphical Display

• Automated purifier regeneration, lab pressure, lab purge (auto valves), antechamber purge & refill, “Smart Train” oxygen controlled blower speed, system diagnostics

Antechamber

Rectangular antechamber with manual evacuation and refill valves.

Rectangular antechamber with manual evacuation and refill valves as standard.
Optional auto antechamber control.

Manual valves
• Stainless steel mini antechamber
• Aluminum main antechamber

Automatic valves (main chamber)
• Stainless steel mini antechamber
• Stainless Steel main antechamber

Vacuum Pump options

TypePart Number
Vacuum Pump Assy, 4.1 CFM (7.0 m3/h)VAC 100617
Vacuum Pump Assy, 6.9 CFM (11.7 m3/h)VAC 100618
Vacuum Pump Assy, 10 CFM (17.0 m3/h)VAC 100619
Vacuum Pump Assy, Dry Scroll, 6.5 CFM (11.0 m3/h)VAC 400711
Vacuum Pump Assy, Dry Scroll, 8.8 CFM (15.0 m3/h)Vac 400006
No Vacuum PumpN/A
4.1 CFM, 6.8 CFM & 10 CFM pumps include outlet mist filter and gravity oil return kit

Analyzers

• Oxygen -Single piece analyzer includes display. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.

• Moisture- Single piece analyzer includes display.

• Oxygen-Integrated with NexGen control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture-Integrated with NexGen control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging.

• Oxygen – LCD display, optional audio alarm and analog output. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture – LCD display, optional audio alarm and analog output

• Oxygen – Integrated with NEXUS II control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture – Integrated with NEXUS II control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging


GENSISNEXGENOMNI-LABNEXUS II
GLOVEBOX:• Single ( 2 port)
• 4, 6 & 8 port via adding additional box modules.
• Single ( 2 port)
• 4, 6 & 8 port via adding additional box modules.
• Single (2-port) OMNI-LAB
• Dual length (4 port-via
additional module attachment
• Single sided 2 port, 3 port, 4 port
• Double sided 4 port, 6 port, 8 port
• Custom designs available
STAND:Completely welded. No assembly required. Can be configured without stand for benchtop mounting.Completely welded. No assembly required.Assembled for shipping
• Option to ship disassembled
• Very simple assembly
Completely welded
• No assembly required
• Stand cover panels
PURIFICATION:Cartridge based purifiers are installed inside the glovebox.
• 2 three speed blowers, one for O2 and one for H2O
• < 1 ppm O2, H2O

NO REGENERATION REQUIRED
Cartridge based purifiers are installed inside the glovebox.
• 2 variable speed blowers one for O2 and one for H2O
• < 1 ppm O2, H2O

NO REGENERATION REQUIRED
Mounted on top of box
• Single speed blower
• Single purifier
• Manual isolation valves
• < 1 ppm O2, H2O
Mounted in stand
• Variable speed blower
• Single or double purifier
• Automatic or manual isolation valves
• < 1ppm O2, H2O
CONTROLS:Box pressure monitoring and control via a panel mounted Photohelic gauge.Box pressure, blower speeds, smart purifier, auto purge, safe purge controlled via a PLC with touch screen display.• Touch EL Screen, 4 lines
• Automated: purifier regeneration, lab pressure, lab purge (manual
exhaust valve), system diagnostics
• Touch Screen Graphical Display
• Automated purifier regeneration, lab pressure, lab purge (auto valves), antechamber purge & refill, “Smart Train” oxygen controlled blower speed, system diagnostics
ANTECHAMBERS:Rectangular antechamber with manual evacuate and refill valves.Rectangular antechamber with manual evacuate and refill valves as standard.
Optional auto antechamber control.
Manual valves
• Stainless steel mini antechamber
• Aluminum main antechamber
Automatic valves (main chamber)
• Stainless steel mini antechamber
• Stainless Steel main antechamber
VACUUM PUMP:4.1 CFM other options available4.1 CFM other options available4.1 CFM other options available4.1 CFM other options available
ANALYZERS: Oxygen -Single piece analyzer includes display. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture- Single piece analyzer includes display.
analyzer includes display. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture- Single piece analyzer includes display.
• Oxygen-Integrated with NexGen control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging.
• Moisture-Integrated with NexGen control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging.
• Oxygen – LCD display, optional audio alarm and analog output. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture – LCD display, optional audio alarm and analog output
•Oxygen – Integrated with NEXUS II control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging. This electrochemical-based sensor is not affected by hydrocarbons and is specific to oxygen.
• Moisture – Integrated with NEXUS II control, standard audio and visual alarms, “Smart Purifier”, trend graph, optional outputs for data logging
genesis glovebox purification cartridges

Cartridge Purification Technology

VAC’s patented cartridge purification systems will remove oxygen and moisture from any glovebox system.

Oxygen Purification

Includes an atmosphere circulation assembly, power supply, and oxygen removal cartridge. These simple plug in components can be installed in any inert glovebox, regardless of manufacturer.

These low cost cartridges are designed to be replaced by fully activated replacements purchased exclusively from Vacuum Atmospheres Company.

Moisture Purification

Includes an atmosphere circulation assembly, power supply, and moisture removal cartridge. These simple plug in components can be installed in any inert glovebox, regardless of manufacturer.

These low cost cartridges are designed to be replaced by fully activated replacements purchased exclusively from Vacuum Atmospheres Company.

Key Benefits

  • No down time.
  • No regeneration gas needed.
  • No purifier service required.
  • Minimizes hazardous waste removal costs.
  • No more regeneration solenoids or controls to wear out.
  • The Genesis purifier cartridges are supplied fully activated and ready for immediate use.
  • Enjoy lower cost of ownership.

No regeneration required
